Product Family

9000 Series

Band

Ka-Band

LO Type

PLL

# of onboard LOs

Triple-band

LO Stability

+/- 25 kHz

Noise Figure

1.5 dB

Input Frequency - Band 1

Ka-Band: 17.30 - 18.30 GHz

Input Frequency - Band 2

Ka-Band: 18.30 - 19.30 GHz

Input Frequency - Band 3

Ka-Band: 19.30 - 20.20 GHz

Output Frequency 1

L-Band: 950 - 1950 MHz

Output Frequency 2

L-Band: 950 - 1950 MHz

Output Frequency 3

L-Band: 950 - 1850 MHz

RF

LO Frequency 1

16.35 GHz

LO Frequency 2

17.35 GHz

LO Frequency 3

18.35 GHz

Control Signal 1

13 V

Control Signal 2

18 V

Control Signal 3

13V + 22 KHz tone

Phase Noise @ 1KHz offset

-70 dBc/Hz

Phase Noise @ 10KHz offset

-80 dBc/Hz

Phase Noise @ 100KHz offset

-90 dBc/Hz

Conversion Gain

58 dBm min

Gain Variation over operating band

4.0 dB p-p

Input VSWR

2.0 : 1

Output VSWR

2.0 : 1

Spurious

-60 dBc (in band) ; -50 dBc (out of band)

Output P1dB compression point

5 dBm

Image Rejection

40 dBc min

ELECTRICAL

Current Drain

350 mA

INTERFACE

RF Input Connector

WR-42 waveguide grooved

RF Output Connector

N-50 Ohm

M&C

LED Indicators

None

ENVIRONMENTAL

Temperature - Operational

-40 to +60°C

Humidity

0 - 95%

PHYSICAL

Dimensions (L x W x H)

133 x 70 x 39 mm

Weight

500 g
