Interface

Ethernet Port

2x 10/100/1000Base-T RJ-45 (JetWave 3220 V3)
2x 10/100/1000Base-T M12 (JetWave 3220-M12 V3)
IEEE 802.3at PoE+ Complaint in Ethernet Port 1

Power Input

4-pin socket for Dual DC Input

Digital Input/ Output

1x Digital Input, 0: +3V max., 1: +11V~+30VDC
1x Relay Output, 1A@24VDC

Console

3-pin Diag. socket for Diagnostic/CLI

Reset

Reset Factory Default after press 7 seconds

Antenna Socket

2x SMA Female Reverse for WIFI Radio1
2x SMA Female Reverse for WIFI Radio2
Nylok pre-applied

Performance

CPU

Qualcomm Atheros Processor and 802.11ac WIFI Chipset

Operating Frequency

5GHz Typical Band: (802.11n WIFI)
FCC: 5.170~5.250GHz, 5.735~5.835GHz
CE: 5.170~5.250GHz
(Programmable for other 5G Band)
2.4GHz Band: (802.11n WIFI)
FCC : 2.412~2.462GHz
CE : 2.412~2.472GHz
(Programmable for different country regulations)

RF Modulation

802.11a/n: OFDM (BPSK, QPSK, 16-QAM, 64QAM)
802.11g/n: OFDM (BPSK,QPSK,16-QAM,64QAM)

RF Output Power (Max. of Avg.)

5.8GHz Band:
19dBm@ 802.11a/n HT20 (MCS0/8, 5180MHz) for
FCC
23dB EIRP for ETSI 301 893 (Band 1)
25dB EIRP for ETSI 301 893 (Band 4)
2.4GHz Band:
21dBm at 802.11g/n HT40 (MCS0/8, 2422MHz) for
FCC
20dB EIRP for CE (ETSI 300 328)
(Controllable for different country regulations)

Sensitivity

5 GHz Band:
802.11a:
-90dBm@6Mbps,1Rx; -75dBm@54Mbps,1Rx
802.11n HT20:
-90dBm@MCS0,1Rx; -71dBm@MCS7,1Rx
802.11n HT40:
-87dBm@MCS0,1Rx; -70dBm@MCS7,1Rx
2.4 GHz Band:
802.11b:
-94dBm@1Mbps,1Rx; -90dBm@11Mbps,1Rx
802.11g:
-92dBm@6Mbps,1Rx; -75dBm@54Mbps,1Rx
802.11n HT20:
-91dBm@MCS0,1Rx; -72dBm@MCS7,1Rx
802.11n HT40:
-88dBm@MCS0,1Rx; -70dBm@MCS7,1Rx
