Electrical data

Nominal voltage

AC/DC 24 V

Nominal voltage frequency

50/60 Hz

Nominal voltage range

AC 19.2...28.8 V / DC 21.6...28.8 V

Power consumption in operation

1.5 W

Power consumption in rest position

0.5 W

Power consumption for wire sizing

3 VA

Connection supply / control

Terminals with cable 1 m, 4x 0.75 mm2 (Terminal 4 mm2)

Parallel operation

Yes (note the performance data)

Functional data

Actuating force motor

1000 N

Operating range Y

0.5...10 V

Input impedance

100 k?

Position feedback U

0.5...10 V

Position feedback U note

Max. 0.5 mA

Position accuracy

±5%

Manual override

with push-button, can be locked

Stroke

20 mm

Running time motor

150 s / 20 mm

Adaptation setting range

manual (automatic on first power-up)

Sound power level, motor

45 dB(A)

Position indication

Mechanical, 5...20 mm stroke

Safety data

Protection class IEC/EN

III, Safety Extra-Low Voltage (SELV)

Power source UL

Class 2 Supply

Degree of protection IEC/EN

IP54

Degree of protection NEMA/UL

NEMA 2

Enclosure

UL Enclosure Type 2

EMC

CE according to 2014/30/EU

Certification IEC/EN

IEC/EN 60730-1 and IEC/EN 60730-2-14

Type of action

Type 1

Rated impulse voltage supply / control

0.8 kV

Pollution degree

3

Ambient humidity

Max. 95% RH, non-condensing

Ambient temperature

0...50°C [32...122°F]

Storage temperature

-40...80°C [-40...176°F]

Servicing

maintenance-free

Weight

Weight

1.1 kg
