Electrical data

Nominal voltage

AC/DC 24 V

Nominal voltage frequency

50/60 Hz

Nominal voltage range

AC 19.2...28.8 V / DC 21.6...28.8 V

Power consumption in operation

2.5 W

Power consumption in rest position

0.5 W

Power consumption for wire sizing

5 VA

Connection supply / control

Cable 1 m, 4 x 0.34 mm2

Parallel operation

Yes (note the performance data)

Functional data

Torque motor

1 Nm

Operating range Y

2...10 V

Input impedance

100 k?

Position feedback U

2...10 V

Direction of motion fail-safe

fix deenergised closed (end stop NC = 0%)

Manual override

with actuator (clicked out)

Running time motor

75 s / 90°

Running time fail-safe

60 s / 90°

Sound power level, motor

35 dB(A)

Sound power level, fail-safe

35 dB(A)

Position indication

Mechanical

Safety data

Protection class IEC/EN

III, Safety Extra-Low Voltage (SELV)

Degree of protection IEC/EN

IP40

EMC

CE according to 2014/30/EU

Certification IEC/EN

IEC/EN 60730-1 and IEC/EN 60730-2-14

Type of action

Type 1.AA

Rated impulse voltage supply / control

0.8 kV

Pollution degree

2

Ambient humidity

Max. 95% RH, non-condensing

Ambient temperature

5...40°C [41...104°F]

Storage temperature

-40...80°C [-40...176°F]

Servicing

maintenance-free

Weight

Weight

0.18 kg

Terms

Abbreviations

POP = Power off position / fail-safe position
PF = Power fail delay time / bridging time
