Electrical data

Nominal voltage

AC 100...240 V

Nominal voltage frequency

50/60 Hz

Nominal voltage range

AC 85...265 V

Power consumption in operation

2 W

Power consumption in rest position

0.5 W

Power consumption for wire sizing

4 VA

Auxiliary switch

1x SPDT, 0...100%

Switching capacity auxiliary switch

1 mA...3 A (0.5 A inductive), DC 5 V...AC 250 V

Connection supply / control

Cable 1 m, 3x 0.75 mm2

Connection auxiliary switch

Cable 1 m, 3x 0.75 mm2

Parallel operation

Yes (note the performance data)

Functional data

Torque motor

5 Nm

Manual override

with push-button, can be locked

Running time motor

90 s / 90°

Sound power level, motor

35 dB(A)

Position indication

Mechanical, pluggable

Safety data

Protection class IEC/EN

II, reinforced insulation

Protection class UL

II, reinforced insulation

Protection class auxiliary switch IEC/EN

II, reinforced insulation

Degree of protection IEC/EN

IP54

Degree of protection NEMA/UL

NEMA 2

Enclosure UL Enclosure

Type 2

EMC

CE according to 2014/30/EU

Low voltage directive

CE according to 2014/35/EU

Certification IEC/EN

IEC/EN 60730-1 and IEC/EN 60730-2-14

UL Approval

cULus according to UL60730-1A, UL60730-2-14 and CAN/CSA E60730-1
The UL marking on the actuator depends on the production site, the device is UL-compliant in any case

Type of action

Type 1

Rated impulse voltage supply / control

2.5 kV

Rated impulse voltage auxiliary switch

2.5 kV

Pollution degree

3

Ambient humidity

Max. 95% RH, non-condensing

Ambient temperature

-30...50°C [-22...122°F]

Storage temperature

-40...80°C [-40...176°F]

Servicing

maintenance-free

Weight

Weight

0.52 kg
