Electrical data

Nominal voltage

AC/DC 24 V

Nominal voltage frequency

50/60 Hz

Nominal voltage range

AC 19.2...28.8 V / DC 19.2...28.8 V

Power consumption in operation

1.5 W

Power consumption in rest position

0.4 W

Power consumption for wire sizing

3 VA

Connection supply / control

Cable 1 m, 4 x 0.75 mm2

Parallel operation

Yes (note the performance data)

Functional data

Torque motor

5 Nm

Operating range Y

2...10 V

Input Impedance

100 k?

Position feedback U

2...10 V

Position feedback U note

Max. 1 mA

Position accuracy

±5%

Direction of motion motor

selectable with switch 0/1

Direction of motion note

Y = 0 V: At switch position 0 (ccw rotation) /1 (cw rotation)

Manual override

with push-button, can be locked

Angle of rotation

Max. 95°

Angle of rotation note

can be limited on both sides with adjustable mechanical end stops

Running time motor

35 s / 90°

Sound power level, motor

45 dB(A)

Mechanical interface

Universal shaft clamp 6...20 mm

Position indication

Mechanically, pluggable

Safety

Protection class IEC/EN

III Safety Extra-Low Voltage (SELV)

Protection class UL

UL Class 2 Supply

Degree of protection IEC/EN

IP54

Degree of protection NEMA/UL

NEMA 2

Enclosure

UL Enclosure Type 2

EMC

CE according to 2014/30/EU

Certification IEC/EN

IEC/EN 60730-1 and IEC/EN 60730-2-14

Certification UL

cULus according to UL60730-1A, UL60730-2-14 and CAN/CSA E60730-1:02

Certification UL note

The UL marking on the actuator depends on the production site, the device is UL-compliant in any case

Mode of operation

Type 1

Rated impulse voltage supply / control

0.8 kV

Control pollution degree

3

Ambient temperature

-30...50°C

Storage temperature

-40...80°C

Ambient humidity

Max. 95% r.H., non-condensing

Servicing

maintenance-free

Weight

1.1 kg
