Electrical data

Nominal voltage

AC/DC 24 V

Nominal voltage frequency

50/60 Hz

Nominal voltage range

AC 19.2...28.8 V / DC 21.6...28.8 V

Power consumption in operation

3.5 W

Power consumption in rest position

1.4 W

Power consumption for wire sizing

6 VA

Connection supply / control

Terminals 4 mm2 (cable ?4...10 mm, 4-wire)

Parallel operation

Yes (note the performance data)

Data bus communication

Communicative control

MP-Bus

Number of nodes

MP-Bus max. 8

Functional data

Torque motor

10 Nm

Torque variable

25%, 50%, 75% reduced

Operating range Y

2...10 V

Input impedance

100 k?

Operating range Y variable

Start point 0.5...30 V
End point 2.5...32 V

Operating modes optional

Open/close
3-point (AC only)
Modulating (DC 0...32 V)

Position feedback U

2...10 V

Position feedback U note

Max. 0.5 mA

Position feedback U variable

Start point 0.5...8 V
End point 2.5...10 V

Position accuracy

±5%

Direction of motion motor

selectable with switch 0/1

Direction of motion variable

electronically reversible

Direction of motion note

Y = 0 V: At switch position 0 (ccw rotation) /
1 (cw rotation)

Manual override

with push-button, can be locked

Angle of rotation

Max. 95°

Angle of rotation note

can be limited on both sides with adjustable mechanical end stops

Running time motor

150 s / 90°

Running time motor variable

43...173 s

Sound power level, motor

35 dB(A)

Adaptation setting range

manual

Adaptation setting range variable

No action
Adaptation when switched on
Adaptation after pushing the manual override button

Override control

MAX (maximum position) = 100%
MIN (minimum position) = 0%
ZS (intermediate position, AC only) = 50%

Override control variable

MAX = (MIN + 32%)...100%
MIN = 0%...(MAX – 32%)
ZS = MIN...MAX

Mechanical interface

Universal shaft clamp 8...26.7 mm

Position indication

Mechanical, pluggable

Safety data

Protection class IEC/EN

III, Safety Extra-Low Voltage (SELV)

Power source UL

Class 2 Supply

Degree of protection IEC/EN

IP54

Degree of protection NEMA/UL

NEMA 2

Housing

UL Enclosure Type 2

EMC

CE according to 2014/30/EU

Certification IEC/EN

IEC/EN 60730-1 and IEC/EN 60730-2-14

UL Approval

cULus according to UL60730-1A, UL60730-2-14 and CAN/CSA E60730-1
The UL marking on the actuator depends on the production site, the device is UL-compliant in any case

Hygiene test

According to VDI 6022 Part 1 / SWKI VA 104-01, cleanable and disinfectable, low emission

Type of action

Type 1

Rated impulse voltage supply / control

0.8 kV

Pollution degree

3

Ambient humidity

max. 95% RH, non-condensing

Ambient temperature

-30...50°C [-22...122°F]

Storage temperature

-40...80°C [-40...176°F]

Servicing

maintenance-free

Weight

Weight

0.71 kg
