Electrical data

Nominal voltage

AC 24...240 V / DC 24...125 V

Nominal voltage frequency

50/60 Hz

Nominal voltage range

AC 19.2...264 V / DC 21.6...137.5 V

Power consumption in operation

6 W

Power consumption in rest position

2.5 W

Power consumption for wire sizing

9.5 VA

Auxiliary switch

2x SPDT, 1x 10% / 1x 11...100%

Switching capacity auxiliary switch

1 mA...3 A (0.5 A inductive), DC 5 V...AC 250 V

Connection supply / control

Cable 1 m, 2x 0.75 mm2

Connection auxiliary switch

Cable 1 m, 6x 0.75 mm2

Parallel operation

Yes

Functional data Torque motor

10 Nm

Torque fail-safe

10 Nm

Direction of motion motor

selectable by mounting L/R

Direction of motion fail-safe

selectable by mounting L/R

Manual override

by means of hand crank and locking switch

Angle of rotation

Max. 95°

Angle of rotation note

adjustable starting at 33% in 2.5% steps (with mechanical end stop)

Running time motor

75 s / 90°

Running time fail-safe

<20 s @ -20...50°C / <60 s @ -30°C

Sound power level, motor 4

5 dB(A)

Mechanical interface

Universal shaft clamp 10...25.4 mm

Position indication

Mechanical

Service life

Min. 60'000 fail-safe positions

Safety data

Protection class IEC/EN

II, reinforced insulation

Protection class UL

II, reinforced insulation

Protection class auxiliary switch IEC/EN

II, reinforced insulation

Degree of protection IEC/EN

IP54

Degree of protection NEMA/UL

NEMA 2

Enclosure

UL Enclosure Type 2

EMC

CE according to 2014/30/EU

Low voltage directive

CE according to 2014/35/EU

Certification IEC/EN

IEC/EN 60730-1 and IEC/EN 60730-2-14

UL Approval

cULus according to UL60730-1A, UL60730-2-14 and CAN/CSA E60730-1
The UL marking on the actuator depends on the production site, the device is UL-compliant in any case

Hygiene test

According to VDI 6022 Part 1 / SWKI VA 104-01, cleanable and disinfectable, low emission

Type of action

Type 1.AA.B

Rated impulse voltage supply / control

4 kV

Rated impulse voltage auxiliary switch

2.5 kV

Pollution degree

3

Ambient humidity

Max. 95% RH, non-condensing

Ambient temperature

-30...50°C [-22...122°F]

Storage temperature

-40...80°C [-40...176°F]

Servicing

maintenance-free

Weight Weight

2.2 kg
