VAISALA溫濕度探頭HPP271技術參數
Property | Description/Value |
Hydrogen peroxide | |
Sensor | PEROXCAP |
Measurement range | 0 ... 2000 ppm |
Measurement temperature range | +5 ... +50 °C (+41 ... +122 °F) |
Repeatability at +25 °C (+77 F) | |
up to 500 ppm H2O2 | ±10 ppm |
up to 1000 ppm H2O2 | ±15 ppm |
Accuracy (including non-linearity, hysteresis, and repeatability) | ±10 ppm or 5 % of reading (whichever is greater) |
Factory calibration uncertainty, at +25 °C (+77 °F), 500 ppm H2O2 | ±10 ppm |
Response time at +23 °C (+73 °F): | |
Response time (T63) | 70 s |
Response time (T90) | 200 s |
Other parameters | |
H2O ppm by volume | |
Operating voltage | Digital output: 15 ... 30 VDC |
Current consumption at +25 °C (+77 °F) | |
In digital mode | Max. 10 mA |
In analog mode | Max. 50 mA |
During purge | Max. 250 mA |
Digital output | |
Interface | RS-485, not isolated; do not use termination on the RS-485 line |
Bit rate | 9600, 19200 (default), 38400, 57600, or 115200 bps |
Parity | None (default), even, odd |
Data bits | 8 |
Stop bits | 1, 2 (default) |
Communication protocol | Modbus RTU v.1.02 |
Analog output | |
Outputs | 2 × 4 ... 20 mA 3-wire current outputs |
Max. load | 500 ? |
Accuracy | ±0.1 % of full scale |
Analog output temperature dependence | 0.005 %/?C (0.003 %/°F) full scale |
Operating environment | |
Operating temperature | +0 ... +70 °C (+32 ... +158 °F) |
Storage temperature | -20 ... +70 °C (-4 ... +158 °F) |
Ambient pressure | Normal atmospheric pressure |
EMC compliance | EN/IEC 61326-1, Industrial Environment |
Mechanical specifications | |
Weight | 110 g (3.88 oz) |
IP rating | IP65 |
Connector | M12/5 male |
Materials | |
Probe body | AISI316L stainless steel |
Filter cap | Porous PTFE |
VAISALA溫濕度探頭HPP271產品介紹
? VAISALA PEROXCAP? H2O2 測量技術具有出色的長期穩定性。
? 汽化 H2O2 測量范圍 0 ... 2000 ppm。
? 堅固的設計允許溫濕度探頭直接安裝在過程環境中。通電時，溫濕度探頭可承受 H2O2 和 H2O 冷凝。溫濕度探頭還可以承受氮?dú)狻?/p>
? 傳感器上的保護過濾器設計用于承受高空氣流速和湍流。
? 傳感器加熱以避免傳感器上的冷凝。
? 化學清洗以優化性能和使用壽命。
? H2O2 和H2O 濃度測量的壓力補償。
? 數字輸出：用于 Modbus 通信的 RS-485 接口。
? 模擬輸出：2 x 4 ... 20 mA。
? 易于插入、拔出。
? 使用常規濕度校準器或 H2O2 蒸汽進行現場校準和調整。
? 可用作獨立溫濕度探頭或與Vaisala Indigo 200 系列變送器一起使用。
? 可以連接到 Vaisala Insight 軟件進行校準和調整、配置、診斷和臨時在線監控。
? Vaisala PEROXCAPa H2O2 measurement technology with excellent long-term stability.
? Vaporized H2O2 measurement range 0 ... 2000 ppm.
? Robust design allowing the probe to be installed directly in the process environment. When powered on, the probe withstands H2O2 and H2O condensation. The probe also withstands nitrogen gas.
? Protective filter over the sensors designed to withstand high air flow rates and turbulence.
? Sensor heating to avoid condensation on the sensors.
? Chemical purge for optimized performance and lifetime.
? Pressure compensation for H2O2 and H2O concentration measurement.
? Digital output: RS-485 interface for Modbus communication.
? Analog output: 2 x 4 ... 20 mA.
? Easy plug-in, plug-out.
? Field calibration and adjustment with a regular humidity calibrator or with H2O2 vapor.
? Can be used as a stand-alone probe or with Vaisala Indigo 200 series transmitters.
? Can be connected to Vaisala Insight software for calibration and adjustment, configuration, diagnostics, and temporary online monitoring.
VAISALA溫濕度探頭HPP270系列其他常用型號：
VAISALA HPP271
VAISALA HPP272
VAISALA Probes NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向制造工業提供高端制造技術和設備。代理經營世界優質的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于VAISALA溫濕度探頭HPP271的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for VAISALA products, please feel free to dial 0086-21-3100 6702/ send request email to [email protected] / browse our website:www.www.jguvm.cn.
VAISALA溫濕度探頭HPP271技術參數及尺寸
