Construction

1.2mm mild sheet steel

IP rating

IP30

Finish

Epay powder coated

Colour- lid& box

Red RAL 3002 (optional grey BS 00 A 05 semi mat)

Mains supply .

230VAC or 115VAC

Mains supply fuse

1.6Amp (FL.6A L250W)

Power supply rating

3 Amps talincudingn btterycharge 28V+1/- 2V

Maximum rpple curent

200 mlilts

Battery Type (Yuas NP)

Two 12 Volt 7Ah sealed lead acid in series

Battery charge vltage

27.6VDC nominal Ctemperature compensated)

Battery charge current

0.7A1 maximum

Battery fuse

20mm, 3.15Aghass

Maximum current draw from batteries

3 amps

Qulescent crrent of panel in mains fall

0.095A

ROV output

Fused at 500mA with electronic fuse

Sounder outputs

24V Fused at 500mA with etronic fuse

Fault relay contact rating

30VDC 1A Amp maximum

Fire relay contact rating

30VDC 1AAmp maximum

Local fire relay contact rating

30VDC 1Amp maximum

First stage contact rating

30VDC 1A Amp maximum

Second stage contact rating

30VDC 1AAmp maximum

Extract contact rating

30VDC 1Amp maximum

Zome quiescent curent

2mA maximum

Terminal capacity

12 AWG

Number of detectors per zone

Dependent on type (maximum 32)

NAC rating

0.5Aper crcuit

Detection clrcuit end ofline

6K8 5% 1/2 Watt resistor

Monitored input end of line

6KB 5% 1/2 Watt rster

Sounder circuit end of line

10K 5% 1/4 Watt rsistr

Extinguishant output EOL

1N4004 Diode

No. of iatig drcuits

3

No. of NAC cicuits

2x1st stage, 1 x2nd stage

Extinguishant release output

Fused at1 Amp

Extinguishant release delay

Adiustable 0to 60 seconds Qin 5 second stpsyp
