Environmental conditions

Operating environment

Indoor use, overvoltage category II

Operating temperature and humidity range

0 °C to +40 °C (+32 °F to +104 °F) / 20 %rh to 85 %rh (no condensation)

Storage temperature and humidity range

-25 °C to +70 °C (-13 °F to +158 °F) / 90 %rh or less (no condensation)

Grounding polarity

Only the output’s COM terminal can be grounded.

Isolation voltage

500 Vdc max

Withstanding voltage

Across the primary circuit and chassis

No abnormalities at 1500 Vac for 1 minute

Across the primary circuit and the output terminals

Insulation resistance

Across the primary circuit and chassis

500 Vdc, 30 MΩ or greater (at 70 %rh humidity or less)

Across the primary circuit and the output terminals

Across the output terminals and chassis

500 Vdc, 1 MΩ or greater (at 70 %rh humidity or less)

Earth continuity

Power cord inlet, across the earth pin and chassis

25 Aac, 0.1 Ω or less

Cooling method

Forced air cooling using a heat sensing variable speed fan.

Safety

Conforms to the requirements of the directive and standard below.
Low Voltage Directive 2014/35/EU *2 EN 61010-1 (Class I *3 , Pollution degree 2 *4 )

Electromagnetic compatibility (EMC)

Conforms to the requirements of the directive and standard below.
EMC Directive 2014/30/EU
EN 61326-1 (Class A *5), EN 55011 (Class A *5, Group 1 *6), EN 61000-3-2, EN 61000-3-3
Applicable condition All of the cables and wires connected to the PBZ are less than 3 m in length.

External dimensions (largest part)

429.5 (16.91”) W × 128 (5.0”) (145 (5.7”)) H × 550 (21.65”) (595(23.4”)) D mm

Weight

Approx. 22 kg (48.50 lb; just the PBZ)

Accessories

Power cord: 1 pc. J1 connector (Socket: 1 pc., Protective covers: 2 pairs, Terminals: 30 pc.) Heavy object warning label: 1 pc.
CD-ROM: 1 pc. Operation manual (Setup guide 1 pc., Quick reference English 1pc., Japanese 1pc. Safety information 1pc.)
