TASKER同軸電纜RG58 PUR技術參數
| Conductor Resistance | 40 ?/Km |
| Capacity Core/Shield | 100 pF/m |
| Velocity of Propagation | 66% |
| Signal Delay | 5,00 ns/m |
| Impedance | 50 ? |
| Min. Bending Radius for single bend | 5xouter ? |
| Min. Bending Radius for Multiple bend | 10xouter ? |
| Insulation Resistance | 10? M?m |
| Min. Screening effectivness | >57 dB |
| Max Rated Voltage | 2 KV |
| Test Voltage | 5 KV |
| Weight | 3,5 kg/100m |
| Recommended connector | tasker SP56 |
| Operative Temperature | -40/+80°C |
TASKER同軸電纜RG58 PUR產品描述
用于無線電和數字視頻的 50 Ω 同軸電纜符合 MIL C17 F 標準,帶有聚氨酯護套,適合戶外使用。
該電纜適用于公共和私人場所的閉路電視安裝、控制攝像機和視頻安全,用于建筑物、封閉空間和開放室外區域的監控以及任何其他符合 RG58 C/U MIL 標準的視頻頻率應用。
適用于實驗室、超市、機場、醫院、大型場所、體育設施等廣播應用和其他設備。
聚氨酯外護套使電纜適合戶外鋪設,并且能夠抵抗大氣因素、紫外線和摩擦,確保電纜的長久使用壽命。
該電纜燃燒時不會產生氣體或鹵素?zé)熿F。
Coaxial cable for radio and Digital Video 50 Ω conformed to MIL C17 F with sheath in Polyurethane and suitable for outdoor use.
This cable is advised for CCTV installations, Control Video-cameras and Video-security in public and private places, for supervisory of buildings, enclosed spaces and open outdoor areas and any other Videofrequency application of an RG58 C/U MIL standards.
Suitable for Broadcast application and other equipments in : Laboratories, Supermarkets, Airports, Hospitals, Big Areas, Sport facilities etc.
The external sheath in Polyurethane makes the cable suitable for outdoor laying and resistant to: atmospheric agents, UV rays and friction, ensuring a long lasting life to the cable.
This cable does not produce Gases or Halogen Smokes in case of combustion.
TASKER同軸電纜其他常用型號:
TASKER RG178 BU
TASKER RG316U
TASKER RG174AU
TASKER RG58CU
TASKER RG58 PUR
TASKER RG223U
TASKER RG213U
TASKER C525
TASKER C526
TASKER C527
