RITTAL接線盒KL1504.510產品參數
Specification | |
Material | |
Enclosure | Sheet steel 1.25 mm; 1.38 mm for KL 1507.510 to KL 1513.510 |
Cover | Sheet steel 1.25 mm |
Surface finish | |
Case and cover | Dipcoat-primed, powder-coated on the outside in textured RAL 7035 |
Protection category | IP 66 to EN 60 529/10.91,Complies with NEMA 4. |
Supply includes | Enclosure, cover with all-round foamed-in PU seal and cover screws, including plastic bushes. |
Width (B1) in mm | 400 |
Height (H1) in mm | 200 |
Depth (T1) in mm | 120 |
RITTAL接線盒KL1504.510產品介紹
材料
外殼：鋼板1.25毫米；適用于KL 1507.510至KL 1513.510的1.38毫米
封面：1.25 mm鋼板
表面光潔度
表殼：浸涂底漆，
RAL 7035紋理粉末噴涂在外部
防護類別
IP 66符合EN 60529 / 10.91，符合NEMA 4。
供貨包括
外殼，用全面發泡的PU密封蓋和包括塑料襯套的蓋螺釘。
Material
Enclosure：Sheet steel 1.25 mm;1.38 mm for KL 1507.510 to KL 1513.510
Cover：Sheet steel 1.25 mm
Surface finish
Case and cover：Dipcoat-primed,
powder-coated on the outside in textured RAL 7035
Protection category
IP 66 to EN 60 529/10.91,Complies with NEMA 4.
Supply includes
Enclosure, cover with all-round foamed-in PU seal and cover screws, including plastic bushes.
RITTAL接線盒KL系列其他常見型號：
RITTAL 1500.510
RITTAL 1529.510
RITTAL 1502.510
RITTAL 1501.510
RITTAL 1503.510
RITTAL 1507.510
RITTAL 1589.510
RITTAL 1504.510
RITTAL 1508.510
RITTAL 1511.510
RITTAL Terminal Box NEW + ORIGINAL+ ONE YEAR WARRANTY
