Power

Maximum power (kVA)

1500

Maximum power (kW)

1350

Input

Nominal Voltage

230VAC

Input voltage range

120VAC- 276VAC

THDi

＜5% at linear load

Input power factor

≥0.99 at 100% nominal load

Input frequency range

(45~55)/ (54~66) Hz

Current consumption

7.8A

Output

Output voltage

208, 220, 230, 240VAC

| Voltage tolerance

± 1%

Nominal current

5.9A

Frequency tolerance

± 0.2Hz (battery mode)

Voltage form

Pure sine wave

Crest factor

3

Switchover time normal operation

Mains <> INVERTER: 0ms

Switchover time (BYPASS, ECO)

Bypass <> INVERTER: maximum 10ms

Efficiency

Efficiency at full load

LINE MODE

> 89% with fully charged batteries

BATTERY MODE

> 84%

ECO MODE

> 95%

Internal batteries

Number of batteries

4

Battery voltage

48VDC

Charching current

Standard 1.5A / XL-version 6A

Charging time

app. 6h to 90%

Typical autonomy times (cos Φ 0,7)

Load 100% (minutes)

5

Load 50% (minutes)

11

XL -versions

Depending on the equipment and number of battery banks
