Shell & plating:

Aluminum:
 - Black anodized (R)
 - Nickel (N)
 - Olive green cadmium (W)
 - Yellow cadmium (G)
 Passivated stainless steel (K)

Insulator:

Thermoplastic

Seal:

Silicone elastomer

Contact:

Copper alloy

Contact plating:

Gold

Endurance:

500 mating cycles (R and K)
250 mating cycles (N, G and W)

Shock:

As per EN3646

Vibration:

From 10 to 2000 Hz - acceleration: 20G

Contact retention in insert:

Size 20: 90 N
 Size 16: 115 N
 Size 12: 136 N

Electrical

Contact resistance:

Size 20: ≤ 1 mΩ
Size 16: ≤ 0.55 mΩ
Size 12: ≤ 0.35 mΩ

Insulation resistance:

≥ 5000 MΩ at 500 Vdc

Max current rating per contact:

Size 20: 7.5A
Size 16: 13A
Size 12: 23A

Shell continuity:

≤ 5 mΩ, plug with grounding ring and receptacle

Environmental

Temperature range:

-65°C to +175°C (G and W)
-65°C to +200°C (R, N and K)

Damp heat:

56 days

Salt spray:

500 hours (G, W and K)
48 hours (N and R)

Leakage:

Method B differential pressure: 100kPa
Maximum leakage flow: 16x10-6 m3/h

Corrosion resistance:

As per EN3646-001

Fluid resistance:

As per EN3646-001
D suffix version: Skydrol withstanding
