Thermocouples:

J, K, N, S, T, E, B

Resolution:

0.1°C or 1°C / 0.1°F or 1°F

Measuring range:

Type K (NiCr-Ni):  -220.0 ... +1372.0°C / -364.0 ... +2502.0°F
Type J (Fe-CuNi):  -200.0 ... +1100.0°C / -328.0 ... +2021.0°F
Type T (Cu-CuNi):  -200.0 ... +400.0° / -328.0... +752.0°F
Type N (NiCrSi-NiSi): -200.0 ... +1300.0° / -328.0 ... +2372.0°F
Type S (Pt10Rh-Pt): -50.0 ... +1768.0°C / -58.0 ... +3215.0°F
Type E (NiCr-CuNi): -60.0 ... +850.0°C / -76.0 ... +1562.0°F
Type B (Pt30Rh-Pt6Rh): +300 ... +1750°C / +572 ... +3182°F
values via interface, the device displays up to 1999.9 °F

Accuracy:

(for thermocouples acc. to DIN EN 60584) ±1digit
(at nominal temperature ± 5K)

Type J, K, N, T, E:

± (0.5°C. + 0.2 % of measured value)

Type S, B:

± (0.8°C. + 0.4 % of measured value)

Temperature drift:

0.01%/K

Point of comparison:

±0.3°C

Nominal temperature:

25°C

Measuring rate:

4 meas./sec

Sensor connection:

2 connection sockets for miniature DIN-plug type K

Display:

Two 4 ? digit LCDs (12.4 mm high and 7 mm high) for measuring values, and for min/ max memories, hold function, etc. as well as additional functional arrows.

Pushbuttons:

6 membrane keys

Output:

3.5 mm audio plug, stereo

Output function:

serial interface

Interface:

Serial interface (3.5mm jack) can be connected to USB or RS232 interface of a PC via electrically isol ated interface adapter USB3100, USB 3100 N, GRS3100 or GRS3105

Power supply:

9V battery (included in scope of supply) as well as additional d.c. connector (diameter of internal pin 1.9 mm) for external 10.5-12V direct voltage supply. (suitable power supply: GNG10/3000)

Power consumption:

approx. 1.0 mA (Output ?out“ = off)
approx. 1.4 mA (Output ?out“ = ser)

Low battery warning:

' bAt '

Working conditions:

-25 ... +50 °C, 0 ... 95 %RH (not condensing)

Storage temperature:

-25 ... +70 °C

Housing:

impact-resistant ABS, membrane keyboard, transparent panel, Front side IP65

Dimensions:

142 x 71 x 26 mm (L x W x D)

Weight:

approx. 155 g
