pH-range:

0... 14 (1 ... 12 for optimum service life)

Operating temperature:

0...80°C

Maximum pressure:

6 bar

Conductity:

> 50 μS/cm

Diaphragms:

Double junction reference system 0(PTFE)

Reference system:

Ag/AgCI (3 mol KCl/gel)

Screw-in thread:

One 1/2" and two 3/4" NPT threads

Sensor head:

SN 6 plug-in head

Material of sensor shaft:

Fibreglass-reinforced PPE

Sensor shaft 0 (below 1/2" NPT thread):

17±0.2mm

Sensor shaft 0 (below 3/4" NPT thread):

22±0.2mm

Fitting length A:

20±0.2 mm from the lower end of the 1/2" thread

Fitting length B:

60±0.2 mm from the lower end of the 3/4" thread

Fitting position:

vertical up to +25。

Storage temperature:

10... 30°C

Typical applications:

Industrial waste water, municipal waste water, cooling water, process water, water in the chemical industry and paper making, generally water with solid fractions

Order number:

1076610
