Minimum Readout

0.1 Micron (switchable determined by the counter used)

Accuracy

Autocollimator Stand Type 3 - Heavy duty with unique precision 2-axis targeting adjustment knobs. Spiral column height adjustment as well as 360° tilt, swivel and rotation.

Measuring Angle

Useable in down or sideways position

Measuring Force - Variable

Down 125-185; Lateral 85 to 125 gf

Response Speed

500m/seconds or better

MFC-101 Compact Counter Tech Specs

Mounting: Can be mounted directly on the Digimicro; Inches/mm: Inch or Metric (switchable); Display: 7-segment LED display; Minimum readout: 0.1, 0.5, 1.0 ,ocrpm (0.000005”, 0.00002”, 0.00005”) setting by switch on back; Reset: Zero reset button on front; RS232: RS232 output (with optional cable); Power: 12V DC adapter - available in 120V or 240V models

TC-101 Table-top Counter Tech Specs

Inches/mm: Inch or Metric (switchable); Display: 10-segment LED display; Minimum readout: 0.01, 0.05, 0.1, 0.5, 1.0 micron (0.0000005”, 0.000002”, 0.000005”, 0.00002”, 0.00005”) dip switch on back; Functions: Zero reset button on front, preset, pulse check, zero blanking; RS232: RS232 output (with optional cable); Power: 12V DC adapter - available in 120V or 240V models; Optional: Extension cable 2M (6 ft) counter to Digimicro head
