nominal sensing distance Sn

1 m

response time

max. 3 ms

controlled height

70 mm

n° of beams

12

beam pitch

6 mm

minimum detectable object

? 6 mm (BX80A/4), ? 2 mm (BX80B/4), ? 3 mm (BX80D/4)

minimum operating distance

30 (BX80A/4), 90 mm (BX80B/5), 550 mm (BX80B/4)

hysteresis

max.15%

repeatibility

0.05

tolerance

0/20% of the nominal sensing distance Sn

operating voltage

12-24 Vcc (standard)

ripple

0.1

no-load supply current

50 mA (receiver), 100 mA (emitter)

load current

100 mA max

leakage current

10 μA  (at max operating voltage)

voltage drop

1.2 V max. (IL = 100 mA)

output type

NPN or PNP- NO/NC selectable

connection

M12 plug 4 pins cable 2 m

excess gain

2° (at nominal distance Sn)

angular displacement

3° (emitter) - 6° (receiver) at Sn distance

emission

infrared (880 nm)

power on delay

500 ms

power supply protections

reversal polarity and voltage transient

output protections

short circuit (auto reset)

operating temperature range

-25°...+50°C (without freeze)

storage temperature

-40°...+80°C

temperature drift

10% Sr

external light

1,500 lux max. (incandescent lamp), 4,500 lux max. (sunlight)

IP mechanical protection

IP67 (EN 60529) - IP69K (special models)

emitter LED

green (supply), red (alarm sync.), yellow (area state)

receiver LED

green (supply), red (alignment), yellow (output state)

housing material

PBT (PC 9K version)

lens materal

PC

tightening torque

25 Nm max.

wight (approximate)

260...300 g connector /  800...820 g cable
