MICRO DETECTORS光電傳感器RX8/00-1A產品參數
Specification | |
Technical features | |
Nominal sensing distance | 2m with white matt paper EG=1,5 |
Thermal drift of Sr | 10% Sr |
Repeat Accuracy | 0.05 |
Sensitivity adjustment | Single-turn potentiometer |
Application | |
Function Principle | Diffuse reflection |
Optic position | Axial |
Outputs | |
Output type | DECOUT ( NPN, PNP) |
Switching frequency | 500Hz |
Electrical data | |
Operating Voltage | 10-30Vdc |
No-Load supply current | 25mA |
Load current | ≤ 100mA |
Leakage current | ≤ 10μA |
Output voltage drop | ≤ 1,2V |
Max ripple content | ≤ 10% |
LED indicators | Rear red (output state), superior red ( alignment), green ( stable signal) |
Time delay before availability | 100ms |
Short-circuit protection | Yes |
Reverse Polarity Protection | Yes |
Emission | Infrared (880nm) |
Interference to external light | ≥ 5000lux (incandescent lamp) |
Mechanical data | |
Dimensions | 26x86,6x50 |
Weight | 75g |
Connections | M12 plug |
Operating temperature | - 25°C…+ 70°C ( without freeze) |
Test/Approvals | |
Approvals | CE |
EMC compatibility | EN 60947-5-2 |
Shocks and vibrations | Vibration IEC 60068-2-6 / Shock IEC 60068-2-28 |
Degree of protection | IP65 |
Accessories | |
Supplied Accessories | ST80 mounting bracket and screws |
MICRO DETECTORS光電傳感器RX8/00-1A產品介紹
?模型：漫反射、回復反射、偏振、穿透光束和背景抑制
?具有高性能和廣泛安裝可能性的系列
?高感應距離和非常小的尺寸
?繼電器輸出或多功能干擾
?定時器功能延遲開啟、延遲關閉、一次性；微調器，用于靈敏度調整
?減少發射的開關，用于穿透光束類型的精細探測
?具有360°可見度的LED對準指示器，2個LED指示器（穩定信號，輸出）
?M12標準插頭電纜出口；軸向和直角支架
? Models: diffuse reflection, retro-reflective, polarized, through-beam and background suppression
? Series with high performances and wide possibilities of installation
? High sensing distance and very small dimensions
? Relay output or multifunctional DECOUT
? Timer function delay on, delay off, one shot; trimmer for sensitivity adjustment
? Switch reducing the emission for fine detection in through-beam types
? LED alignment indicator with 360° visibility, 2 LED indicators (stable signal, output)
? M12 standard plug cable exit; axial and right angle brackets
MICRO DETECTOR光電傳感器RX8/00-1A其他常見型號：
MICRO DETECTORS RXL/00-1A
MICRO DETECTORS RXL/0T-1A
MICRO DETECTORS XL/00-3A
MICRO DETECTORS XL/0T-3A
MICRO DETECTORS X6/00-1A
MICRO DETECTORS X6/0T-1A
MICRO DETECTORS X6/00-3A
MICRO DETECTORS X6/0T-3A
MICRO DETECTORS X8/00-1A
MICRO DETECTORS X8/0T-1A
MICRO DETECTORS X8/00-3A
MICRO DETECTORS X8/0T-3A
MICRO DETECTORS Photoelectric sensor NEW + ORIGINAL+ ONE YEAR WARRANTY
