Band

Ku-Band

Input Frequency Band 1

Ku-Band: 10.70 - 11.70 GHz

Input Frequency Band 2

Ku-Band: 11.70 - 12.75 GHz

Lo Stability

+/- 10 kHz

Lo Type

PLL

Noise Figure

0.8 dB

Output Frequency 1

L-Band: 950 - 1950 MHz

Output Frequency 2

L-Band: 1100 - 2150 MHz

RF SPECIFICATIONS

Control Signal 1

13 V

Control Signal 2

18 V

Conversion Gain

60 dB typ

Input VSWR

2.5 : 1

Lo Frequency 1

9.75 GHz

Lo Frequency 2

10.60 GHz

Output VSWR

2.5 : 1

ELECTRICAL SPECIFICATIONS

Current Drain

350 mA

Power Requirements

12 - 24 V

INTERFACE SPECIFICATIONS

RF Input Connector

WR-75 waveguide grooved

RF Output Connector

N-50 Ohm

ENVIRONMENTAL SPECIFICATIONS

Temperature Operational

-40 to +60°C

Temperature Storage

-40 to +80°C

Weight

400g

PHYSICAL SPECIFICATIONS

Dimensions (LxWxH)

128 x 60 x 42 mm
