Nominal voltage

AC/DC 24 V

Nominal voltage frequency

50/60 Hz

Nominal voltage range

AC 19.2...28.8 V / DC 21.6...28.8 V

Power consumption in operation

7 W

Power consumption in rest position

2 W

Power consumption for wire sizing

10 VA

Power consumption for wire sizing note

Imax 8.3 A @ 5 ms

Auxiliary switch

2 x SPDT

Switching capacity auxiliary switch

1 mA...6 A (3 A inductive), DC 5 V...AC 250 V (II, reinforced insulation)

Switching points auxiliary switch

5° / 80°

Connection supply / control

Cable 1 m, 2 x 0.75 mm2 (halogen-free)

Connection auxiliary switch

Cable 1 m, 6 x 0.75 mm2 (halogen-free)

Functional data

Torque motor

18 Nm

Torque fail-safe

12 Nm

Direction of motion motor

selectable by mounting L/R

Manual override

with position stop

Angle of rotation

Max. 95°

Running time motor

<120 s / 90°

Running time fail-safe

16 s @ 20°C

Sound power level, motor

45 dB(A)

Sound power level, fail-safe

63 dB(A)

Mechanical interface

Form fit 12x12 mm, non-continuous hollow shaft

Position indication

Mechanically, with pointer

Service life

Min. 60'000 safety positions

Safety data

Protection class IEC/EN

III, Safety Extra-Low Voltage (SELV)

Protection class auxiliary switch IEC/EN

II, reinforced insulation

Degree of protection IEC/EN

IP54

Degree of protection note

IP protection in all mounting positions

EMC

CE according to 2014/30/EU

Low voltage directive

CE according to 2014/35/EU

Certification IEC/EN

IEC/EN 60730-1 and IEC/EN 60730-2-14

Mode of operation

Type 1.AA.B

Rated impulse voltage supply / control

0.8 kV

Pollution degree

3

Ambient temperature normal operation

-30...50°C

Ambient temperature safety operation

The safety position will be attained up to max. 75°C

Safety data

Storage temperature

-40...50°C

Ambient humidity

Max. 95% RH, non-condensing

Servicing

maintenance-free

Weight

2.6 kg
