Electrical data

Nominal voltage

AC/DC 24 V

Nominal voltage frequency

50/60 Hz

Nominal voltage range

AC 19.2...28.8 V / DC 21.6...28.8 V

Power consumption in operation

10 W

Power consumption in rest position

2 W

Power consumption for wire sizing

12.5 VA

Power consumption for wire sizing note

Imax 8.3 A @ 5 ms

Auxiliary switch

2x SPDT

Switching capacity auxiliary switch

1 mA...6 A (3 A inductive), DC 5 V...AC 250 V

Switching points auxiliary switch

5° / 80°

Connection supply / control

Cable 1 m, 2x 0.75 mm2 (halogen-free)

Connection auxiliary switch

Cable 1 m, 6x 0.75 mm2 (halogen-free)

Functional data

Torque motor

20 Nm (see Service life)

Torque fail-safe

20 Nm (see Service life)

Direction of motion motor

selectable by mounting L/R

Manual override

with position stop

Angle of rotation

Max. 95°

Running time motor

<60 s / 90°

Running time fail-safe

<30 s @ 20°C

Sound power level, motor

55 dB(A)

Sound power level, fail-safe

62 dB(A)

Mechanical interface

Form fit 12x12 mm, non-continuous hollow

shaft

Position indication

Mechanical, with pointer

Service life

Min. 10'200 safety positions @ 15 Nm (typically),
followed by 50 safety positions @ 20 Nm (max.)

Safety data

Protection class IEC/EN

III, Safety Extra-Low Voltage (SELV)

Protection class auxiliary switch IEC/EN

II, reinforced insulation

Degree of protection IEC/EN

IP54
IP protection in all mounting orientations

EMC

CE according to 2014/30/EU

Low voltage directive

CE according to 2014/35/EU

Certification IEC/EN

IEC/EN 60730-1 and IEC/EN 60730-2-14

Type of action

Type 1.AA.B

Rated impulse voltage supply / control

0.8 kV

Pollution degree

3

Ambient humidity

Max. 95% RH, non-condensing

Ambient temperature normal operation

-30...50°C [-22...122°F]

Ambient temperature safety operation

The safety position will be attained up to max. 75°C

Storage temperature

-40...50°C [-40...122°F]

Servicing

maintenance-free

Weight

Weight

2.5 kg
