Series name

Heavy duty

Product or component type

Limit switch

Product specific application

Hazardous location box

Device short name

9007CR

Body type

Fixed

Head type

Rotary head

Material

Metal

Fixing mode

By the body

Movement of operating head

Rotary

Type of operator

Zinc spring return without operating lever (-)9007C lever

Switch actuation

From left and right
CW and CCW

Type of approach

1 or 2 programmable direction lateral approach

Electrical connection

(12...22 AWG) screw-clamp terminals, 1...2

Cable entry

1 entry for 1/2" - 14 NPT conforming to ANSI
B1.20.1

Number of poles

1

Contacts type and composition

NC-NO

Contacts operation

Snap action

Positive opening

Without

Level or class

Class I Division 1 Groups B/C/D
Class II Division 1 Groups E/F/G

Body material

Aluminum

Head material

Zinc

Function available

﹣

Switch function

SPDT-DB

Contact form

Form Z

Contacts material

Silver contacts

Terminals description ISO n°1

(1-2)NC
(3-4)NO

Minimum torque for tripping

4 lbf.in

Maximum actuation speed

90 ft/min with 45° cam angle, levers only
130 ft/min with 30° cam angle, levers only

Tripping angle

10 °

Maximum displacement angle

90 °

Repeat accuracy

+/- 0.002 in linear travel of cam

[Ie] rated operational current

1.2 A at 600 V AC, A600 conforming to NEMA
1.5 A at 480 V AC, A600 conforming to NEMA
3 A at 240 V AC, A600 conforming to NEMA
6 A at 120 V AC, A600 conforming to NEMA
0.1 A at 600 V DC, Q600 conforming to NEMA
0.27 A at 250 V AC, Q600 conforming to NEMA
0.55 A at 125 V DC, Q600 conforming to NEMA

[Ithe] conventional enclosed thermal current

10 A

[Ui] rated insulation voltage

600 V degree of pollution 3 conforming to UL 508 for contact block
600 V degree of pollution 3 conforming to CSA C22-2 No 14 for contact block

[Uimp] rated impulse withstand voltage

2.5 kV AC for 1 min conforming to CE
2.2 kV AC for 1 min conforming to UL
2.64 kV AC for 1 s conforming to CSA

Short circuit protection

10 A by CC fuse, protection type: non-time delay

Electrical durability

1000000 cycles

Local signalling

Without

Mechanical durability

10000000 cycles

Width

2.72 in

Height

6.1 in

Depth

2.79 in

Product weight

2.25 lb(US)

CAD overall width

2.72 in

CAD overall height

6.1 in

CAD overall depth

2.79 in

Shock resistance

60 gn (duration = 9 ms) conforming to IEC 60068-2-27

Vibration resistance

25 gn (f = 10...150 Hz) conforming to IEC 60068-2-6

NEMA degree of protection

NEMA 1 conforming to Nema type 250
NEMA 2 conforming to Nema type 250
NEMA 4 conforming to Nema type 250
NEMA 6 conforming to Nema type 250
NEMA 6P conforming to Nema type 250
NEMA 12 conforming to Nema type 250
NEMA 13 conforming to Nema type 250

IP degree of protection

IP67 conforming to IEC 60529

Class of protection against electric shock

Class 0 conforming to IEC 61140

Ambient air temperature for operation

-20...185 °F for hazardous location

Ambient air temperature for storage

-20...185 °F

Environmental characteristic

Standard environment

Protective treatment

Epoxy powder coat
