ANYBUS網關AB7652-F技術參數
General | |
Net Weight (g) | 400 |
Packed Width (mm) | 17 |
Packed Height (mm) | 9 |
Packed Depth (mm) | 19 |
Packed Weight (g) | 600 |
Operating Temperature °C Min | -25 |
Operating Temperature °C Max | 65 |
Storage Temperature °C Min | -40 |
Storage Temperature °C Max | 85 |
Current Consumption Type Value at Vcc Nom (mA) | 200mA @ 24V DC |
Current Consumption Max value at Vcc nom (mA) | 400mA @ 24V DC |
Input Voltage (V) | 24V DC (-20% to +20%) |
Power Connector | 2-pin, 5.08 Phoenix plug connector |
Isolation | TRUE |
Mounting | DIN-rail (EN 50022 standard) |
Housing Materials | Aluminum, Plastic |
Packaging Material | Cardboard |
Identification and Status | |
Product ID | AB7652-F |
Country of Origin | Sweden |
HS Code | 8517620000 |
Export Control Classification Number (ECCN) | 5A991.b.1 |
Supply Risk Factor ERP | Used in Volume 01 |
Certifications and Standards | |
Protection Class IP | IP20 |
UL Information | E214107: Ord.Loc UL508, CSA C22.2 NO. 142 |
Environment | EN 61000-6-4, |
ANYBUS網關AB7652-F產品介紹
Anybus X-gateway PROFINET IO 從站 - PROFIBUS DP-V0 從站可將任何 PROFINET IO 系統連接到任何 PROFIBUS DP-V0 控制系統。Anybus 網關可確保不同工業網絡之間可靠、安全、高速的數據傳輸，同時易于使用。
The Anybus X-gateway PROFINET IO Slave - PROFIBUS DP-V0 Slave enables you to connect any PROFINET IO system to any PROFIBUS DP-V0 control system. Anybus gateways ensure reliable, secure, high-speed data transfers between different industrial networks while being easy to use.
ANYBUS網關其他常用型號：
ANYBUS AB7554-F
ANYBUS AB7558-F
ANYBUS AB7670-F
ANYBUS AB7503-F
ANYBUS AB7899-F
ANYBUS AB7673-F
ANYBUS AB7566-F
ANYBUS AB7566-F
ANYBUS AB7654-F
ANYBUS AB7510-F
ANYBUS AB7635-F
ANYBUS AB7652-F
ANYBUS GATEWAY NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向制造工業提供高端制造技術和設備。代理經營世界優質的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于ANYBUS網關AB7652-F的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for ANYBUS products, please feel free to dial 0086-21-3100 6702/ send request email to [email protected] / browse our website:www.www.jguvm.cn.
