Identification & Status

Brand

Anybus

Country of Origin

Sweden

Dual Usage

No

Export Control Classification Number (ECCN)

5A991.b.1

Item Number

AB7653-F

Certifications & Standards

CE

Yes

UL

Yes

UL Information

E214107: Ord.Loc UL508, CSA C22.2 NO. 142

Environment

EN 61000-6-4, EN 55016-2-3 Class A, EN 55022 Class A, EN 61000-6-2, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6

Waste Certification (WEEE)

Yes

WEEE Category

IT and telecommunications equipment

Protection Class IP

IP20

Recycle / Disposal

TRUE

RoHS Compliant

Yes

Physical Features

Contains Battery

No

Connectors / Input / Output

2x RJ45, 1x 5-pin, 5.08 Phoenix plug connector, USB-B Config port

DIP & Rotary Switches

1x 8-dip switch DEV MacID + Baud rate

General

Net Width (mm)

44 mm

Net Height (mm)

127 mm

Net Depth (mm)

114 mm

Net Weight (g)

400 g

Mounting

DIN-rail (EN 50022 standard)

Current Consumption Type Value at Vcc Nom (mA)

200mA @ 24V DC

Current Consumption Max value at Vcc nom (mA)

400mA @ 24V DC

Input Voltage (V)

24V DC (-20% to +20%)

Power Connector

2-pin, 5.08 Phoenix plug connector

Isolation

TRUE

Operating Temperature °C Min

-25 °C

Operating Temperature °C Max

65 °C

Storage Temperature °C Min

-40 °C

Storage Temperature °C Max

85 °C

Housing Materials

Aluminum, Plastic

Packaging Material

Cardboard

Packed Depth (mm)

19 mm

Packed Height (mm)

9 mm

Packed Weight (g)

600 g

Packed Width (mm)

17 mm

DeviceNet Features

DeviceNet Input Data Size

512 bytes

DeviceNet Mode

Adapter / Slave

DeviceNet Output Data Size

512 bytes

DeviceNet Baud Rate

125-500 kbit/s

DeviceNet Configuration File

EDS available

PROFINET Features

PROFINET Mode

Slave

PROFINET Supported Functionality

Soft Real-Time (RT); Max 64 slots / 1 sub-slot; DCP support; Acyclic Data exchange

PROFINET Bandwidth

10/100Mbit full/half duplex down to 1ms

PROFINET Input Data Size

512 bytes

PROFINET Output Data Size

512 bytes

PROFINET Configuration File

GSDML available
