Nominal voltage

24 VAC/DC, 50/60 Hz

Nominal voltage range

19...29 VAC/DC

Power consumption motor (motion)

7,0 W

Power consumption standby (end position)

1,0 W

Wire sizing

9,0 VA

Control

continuous control
(0)2...10 VDC /Ri > (100 kΩ) 50 kΩ resolution 80mV
(0)4...20 mA / Rext. = 500 Ωresolution 0,16 mA

Feedback signal

(0)2...10 VDC, max. 5 mA

Auxiliary switch

-

Contact load

-

Switching point

-

Connection motor

cable 1000 mm, 4 x 0,75 mm2 (halogen free)

Connection feedback potentiometer

-

Connection auxiliary switch

-

Connection GUAC

-

Functional data

Torque

5 Nm

Damper size

up to approx. 1 m2

Synchronized speed

±5%

Direction of rotation

selected by switch

Manual override

gearing latch disengaged with
pushbutton, self-resetting

Angle of rotation

0°...max. 95° can be limited with adjustable mechanical end stops ;after changing the angle of rotation, a adaptation drive must be made

Running time

2 s / 90°

Sound power level

< 55 dB(A)

Shaft coupling

clamp ? 8-15 mm / ? 8-20 mm

Position indication

mechanical with pointer

Service life

> 100 000 cycles (0°...95°...0°)
> 1 500 000 partial cycles (max.±5°)

Safety

Protection class

III (safety extra-low voltage)

Degree of protection

IP 54 (cable downwards)

EMC

CE (2014/30/EU)

LVD

CE (2014/35/EU)

RoHS

CE (2011/65/EU - 2015/863/EU -2017/2102/EU)

Mode of operation

Typ 1 (EN 60730-1)

Rated impulse voltage

0,8 kV (EN 60730-1)

Control pollution degree

3 (EN 60730-1)

Ambient temperature normal operation

-30°C...+50°C

Storage temperature

-30°C...+80°C

Ambient humidity

5...95% r.H., non condensing (EN60730-1)

Maintenance

maintenance free

Dimensions / Weight

Dimensions

168 x 67 x 88 mm

Weight

700 g
