Nominal voltage

24 VAC/DC, 50/60 Hz

Voltage range

19...29 VAC/DC

Power consumption motor (motion)

13,0 W

Power consumption standby (end position)

1,0 W

Wire sizing

17,0 VA

Control

continuous control (0)2...10 VDC / Ri > 100 kΩ resolution 40 mV (0)4...20 mA / Rext. = 500 Ω resolution 0,08 mA

Feedback signal

(0)2...10 VDC, max. 5 mA

Connection motor

cable 1000 mm, 4 x 0,75 mm2 (halogen free)

Torque

10 Nm

Damper size

up to approx. 2 m2

Synchronized speed

±5%

Direction of rotation

selected by switch

Manual override

gearing latch disengaged with pushbutton, self-resetting

Angle of rotation

0°...max. 95° can be limited with adjustable mechanical end stops; after changing the angle of rotation, an adaptation drive must be made

Running time

3 s / 90°

Sound power level

< 55 dB(A)

Shaft coupling

clamp ? 8-15 mm / ? 8-20 mm

Position indication

mechanical with pointer

Service life

> 100 000 cycles (0°...95°...0°)
> 1 500 000 partial cycles (max. ±5°)

Protection class

III (safety extra-low voltage)

Degree of protection

IP 54 (cable downwards)

Cable mounting type

Type Z (EN 60730-1)

EMC

CE (2014/30/EU)

LVD

CE (2014/35/EU)

RoHS

CE (2011/65/EU - 2015/863/EU - 2017/2102/EU)

Mode of operation

Typ 1.AA.B (EN 60730-1)

Rated impulse voltage supply / control

0,8 kV

Control pollution degree

3 (EN 60730-1)

Ambient temperature normal operation

-30°C...+50°C

Storage temperature

-30°C...+80°C

Ambient humidity

5...95% r.H., non condensing

Maintenance

maintenance free

Dimensions

168 x 67 x 88 mm

Weight

700 g
